SJW Series 220v 380v 400v 415v 440v Avr 20kva 30kva 50kva 60kva 75kva 100kva 3 Phase Automatic Voltage Regulator Industrial Stabilizer

SJW Series 220v 380v 400v 415v 440v Avr 20kva 30kva 50kva 60kva 75kva 100kva 3 Phase Automatic Voltage Regulator Industrial Stabilizer
SJW Series 220v 380v 400v 415v 440v Avr 20kva 30kva 50kva 60kva 75kva 100kva 3 Phase Automatic Voltage Regulator Industrial Stabilizer
SJW Series 220v 380v 400v 415v 440v Avr 20kva 30kva 50kva 60kva 75kva 100kva 3 Phase Automatic Voltage Regulator Industrial Stabilizer
SJW Series 220v 380v 400v 415v 440v Avr 20kva 30kva 50kva 60kva 75kva 100kva 3 Phase Automatic Voltage Regulator Industrial Stabilizer
SJW Series 220v 380v 400v 415v 440v Avr 20kva 30kva 50kva 60kva 75kva 100kva 3 Phase Automatic Voltage Regulator Industrial Stabilizer
SJW Series 220v 380v 400v 415v 440v Avr 20kva 30kva 50kva 60kva 75kva 100kva 3 Phase Automatic Voltage Regulator Industrial Stabilizer

SJW Series 220v 380v 400v 415v 440v Avr 20kva 30kva 50kva 60kva 75kva 100kva 3 Phase Automatic Voltage Regulator Industrial Stabilizer

Input: AC 3 phase 250-450V or customized

Output: AC 3 phase 380V or customized

Power capacity: 10~120KVA

  • Brand :

    Green Energy
  • OEM/ODM :

    Yes
Technology
Servo MOtor Control System +Micro compute programmed control
Input voltage
three phase AC 240 - 450V
Output voltage
three phase 380V ±1.5% or 3.5%
Phase
Three phase
Frequency
50-60Hz
Adjust time
<1 sec.(against 10% input voltage deviation)
Protection over voltage
< 430 ± 2V
Protection lack voltage
< 320 ± 2V
Delay
3 second
Temperature protection
110℃±10℃
Ambient temperature
-10~45℃
Relative humidity
<90%
Wave form distortion
No additional wave form distortion
Efficiency
>95%
Dielectric strength
1500V/min
Insulation resistance
≥ 5MΩ
protection
over/lower voltage, overload,lighting, temperature protection
Display
Informative LED display
